SANA Semiconductors is a fabless company specializing in developing Power Amplifier Modules (PAMs) for mobile phones and other 3G/4G/5G wireless devices.

Apart from offering the traditional pin compatible solutions, SANA leads the industry by delivering single band PAMs in the form factor of 2 mm x 2 mm and dual and quad band PAMs in 2.5 mm x 3 mm, which are the world’s smallest in the respective classes.

By employing advanced monolithic designs and simplified packaging methodologies, SANA has leading edge technical strengths and experiences in producing single, dual, triple and quad band PAMs in reduced sizes and with top performance for 3G/4G/5G applications.




Products

4*6.8
4 mm x 6.8 mm Multimode Multiband

SM54068-1 Power Amplifier Module (PAM) is a fully matched 42 pin surface mount module developed for multimode multiband (MMMB) applications. This MMMB PAM covers the low, mid and high bands, and meets the stringent spectral linearity requirements of CDMA, WCDMA, TD SCDMA and LTE with high power added efficiency (PAE). The self-contained 4.0 mm x 6.8 mm module package incorporates 50 ohm input and output matching networks. A CMOS controller uses standard MIPI®controls to provide the internal control interface and operation.

3*3
3 mm x 3 mm Multimode Multiband

The SM53030 Power Amplifier Module (PAM) is a fully matched 20-pin surface-mount module developed for LTE applications. This PAM covers the full High- Band (23002690MHz), and meets the stringent spectral linearity requirements of LTE with high power added efficiency (PAE). The self-contained 3.0mmx3.0mm module package incorporates 50-ohminput and output matching networks. A CMOS controller uses standard MIPI® controls to provide the internal control interface and operation.

dual/quad band
Dual-band & Quad-band

SANA’s Power Amplifier Modules by the exceptionally small form factor of 2.5 mm x 3 mm are grouped under the SD3xxx series. Designed for use in LTE, WCDMA, HSDPA, HSUPA and HSPA+ applications, they surpass competing products by using a single socket and form factor for single, dual, triple and quad bands.

singleband
Single-band

SANA proudly presents its S2xx series, the world’s smallest Power Amplifier Modules (PAMs) by the form factor of 2 mm x 2 mm.

Measuring 3 mm by 3 mm by 0.9 mm, SANA’s Power Amplifier Module in the S3xxx series are highly competitive in the market with its high efficiency, power down control, integrated directional coupler and optimization for DC-DC supply.



Product Portfolio

SANA offers an extensive and growing portfolio of PAM's based on InGaP HBT and BiHEMT processes. Apart from novel products in small form factors, a comprehensive range of pin compatible standard device are also available.

×

Product Portfolio

Advance Small Form Factor Portfolio

Part Number Description Size mm2
SDL300 UMTS Band 3/4/9/10 (1710-1785MHz) 2.5 x 3
SDL405 Dual band, bands (3,4)/5 WCDMA/LTE 2.5 x 3
SDL205 BC0 BC1 LTE Band 2/5 2.5 x 3
SDL108 Dual band, bands 1/8 WCDMA/LTE 2.5 x 3
SDL100 Band 1/2 2.5 x 3
SDL008 Band 8 2.5 x 3
SDL005 Band 5 2.5 x 3
SD3205 Dual band, bands 2/5 WCDMA/LTE 2.5 x 3
SD3108-4 Dual band, bands 1/8 WCDMA/LTE 2.5 x 3
SD3105 Dual band, bands 1/5 WCDMA/LTE 2.5 x 3
SDL217 Multi-band for IoT 2.5 x 3
SD3008 Band 8, WCDMA/LTE 2.5 x 3
SD3005 Band 5, WCDMA/LTE 2.5 x 3
SD300 Band 20 LTE 2.5 x 3
S2C6 Band 26 (814-849MHz) 2 x 2
S2B7 Band 12/17, LTE 2 x 2
S2B3 Band 13/14, LTE 2 x 2
S2A8 Band 8, WCDMA/LTE 2 x 2
×

Product Portfolio

Pin to Pin Compatible

Part Number Description Size mm2
SM53030-1 Multi band, band 7/40/41/30/38 with RX switch, MIPI® 3 x 3
ST07 Band 7/40/41, MIPI® 2.5 x 2
SM54068-1 Multiband 3G/LTE Handsets and Data Cards, WCDMA Bands, TD-SCDMA Bands, FDD LTE Bands ,TDD-LTE Bands , MIPI® 4 x 6.8
SM54068-LM MMMB, Band 3/4 (1710-1785MHz), Band 5/26 (814-849MHz), MIPI® 4 x 6.8
SM54068-11R MMMB, Band 3/4/40, MIPI® 4 x 6.8
S423 WCDMA/LTE 4.2 x 3
S3307 Band 7, LTE 3 x 3
S3340 Band 40, LTE 3 x 3
S3330 Band 30, LTE 3 x 3
S3303 Band 3/4/9/10, WCDMA/LTE 3 x 3
S3301 Band 1/2, WCDMA/LTE 3 x 3
S3228 Band 28, LTE 3 x 3
S3220 Band 20, LTE 3 x 3
S3217 Band 12/17, LTE 3 x 3
S3213 Band 13/14, LTE 3 x 3
S3208 Band 8, WCDMA/LTE 3 x 3
S3205 Band 5, WCDMA/LTE 3 x 3

* When MIPI® not mentioned, control is GPIO


Benchmarks


×

Benchmark: SM54068-1

|
Comparison against QM56022 – Low Band
Comparison against QM56022 – Mid Band
Comparison against QM56022 – High Band
Comparison against Sky77638 – Low Band
Comparison against Sky77638 – Mid Band
Comparison against Sky77638 – High Band
×

Benchmark: SM53030

Info

Performance as tested in Galaxy J610 versus SKY77786-1

System Performance as tested in Galaxy A5 versus SKY77786-1

Performance as tested and reported by Huawei

×

Some Historical Benchmarks

August 2015

January 2015

May 2014


March 2014

February 2014

January 2014




Technology


Example image

The technologies behind SANA’s PAMs are not only advanced but, more importantly, effective in achieving target level of miniaturization.

SANA’s monolithic high performance PAMs are designed based on GaAs and other process technologies, and have no Surface Mounted Devices (SMD) in the modules. The interfaces of SANA’s multimode multiband power amplifiers (MMMB PAs) are developed in accordance with MIPI® Alliance Specification for RF Front-End (RFFE) Control Interface. In addition, SANA employs pioneering packaging technologies based on flip chip to enable form factor reduction for MMMB PAs. Furthermore, SANA has been working on Advanced Envelope Tracking Power Amplifier Architectures for LTE.

SANA has developed platforms for rapid development of custom multiband PAs.


World Leader in Size Reduction

  • SANA’s 2 mm x 2 mm Single band PAMs for 3G & 4G
    • World's Smallest
    • 56% smaller than common 3 mm x 3 mm PAMs
  • SANA’s 2.5 mm x 3 mm Quad/Dual/Single PAMs for 3G & 4G
    • World’s smallest in dual & quad class
    • A single socket & form factor for single, dual, triple and quad bands

Technically Advanced Product Portfolio

  • Advanced monolithic designs
  • Simplified packaging methodologies
  • Advanced designs that are uniquely simple
  • No SMD components in single and dual band modules
    • Higher reliability
    • Higher yields
    • Lower cost
    • High Production Capacity


Uniquely Simple Advanced Design





Technical Capabilities




Milestones


Founded by a technology entrepreneur from Silicon Valley in 2009, SANA has been focusing on developing Power Amplifier Modules (PAMs) for mobile phones and other 3G/4G/5G wireless devices.

SANA has established its production with sizable production capacity catered to rapid surge in demand. Currently SANA is offering a wide range of PAMs to handset and mobile devices manufacturers in China and Korea.



Past Project Samples
